Dominant Power & Precision
The Shuttle SLAM redefines what’s possible. Thanks to its Bosch Performance Line SX drive system, you get an awe-inspiring 600 watts of peak power, delivering a surge of energy that feels as natural as your own pedal stroke. No extra weight, no compromise. With a lightweight, sleek frame and a 400Wh in-frame battery, the Shuttle SLAM is built for unmatched agility—handling technical lines and rough terrain with the kind of precision that’ll leave you wondering if there’s even a motor at all.
The Latest Bosch Performance Drive System
Powered by the Bosch Performance Line SX drive system, all Shuttle SL/AM models now feature Bosch’s lightest and most compact motor ever—delivering a seamless, natural boost with up to 600 watts of peak power and 60Nm of torque. Paired with a sleek 400Wh battery, the SX system keeps weight low and stoke high, giving the Shuttle SL/AM its signature playful, responsive character. Need more range? The optional Bosch PowerMore 250 range extender adds 250Wh of energy in a compact, water bottle-shaped package that mounts cleanly to your frame and weighs just 3.3 lbs (1.6 kg), so you can ride further without compromise.
Performance Without Limits
This bike doesn’t just deliver power— it turns every climb into an open invitation and every descent into a masterclass in control. The dw-link™ suspension is fine-tuned to deliver lightning-fast acceleration, ensuring every climb is a breeze and every descent feels like a thrilling adventure. Whether you’re navigating technical descents, charging up steep climbs, or flying through berms, the Shuttle SL/AM gives you the confidence to tackle it all with ease.
Power Perfected
Born from the fusion of agility and electric ferocity, the Shuttle SL/AM is built to blur boundaries. At under 40 pounds, its featherweight carbon frame and Bosch Performance Line SX system deliver a seamless surge of power that feels alive underfoot.
Product Details
- Full-carbon frame constructed with Pivot’s proprietary molding technology
- Bosch Performance SX lightweight drive unit on every build level
- Long-lasting 400Wh battery
- Bosch PowerMore 250 range extender compatible
- Adjustable geometry via Pivot flip chip
- 160mm FOX 36 fork
- 150mm rear wheel travel
- Mixed-wheel setup optional
- Clean internal routing with Pivot Cable Port System
Bike Geometry
| |
|
XS |
SM |
MD |
LG |
XL |
| A |
Seat Tube Length (C-T) |
34.3 cm |
37.8 cm |
39.9 cm |
43.2 cm |
47.0 cm |
| B |
Top Tube Length (Eff.) |
57.4 cm |
60.3 cm |
63.1 cm |
64.8 cm |
67.0 cm |
| C |
Head Tube Length |
9.5 cm |
11.0 cm |
12.0 cm |
13.0 cm |
14.0 cm |
| D |
Head Tube Angle |
64.1° |
64.1° |
64.1° |
64.1° |
64.1° |
| E |
Seat Tube Angle (Eff.) |
76.5° |
76.5° |
76.5° |
76.5° |
76.5° |
| F |
Chain Stay Length |
44.4 cm |
44.4 cm |
44.4 cm |
44.4 cm |
44.4 cm |
| G |
Bottom Bracket Height |
34.5 cm |
34.5 cm |
34.5 cm |
34.5 cm |
34.5 cm |
| H |
Bottom Bracket Drop |
2.3 cm |
2.9 cm |
2.9 cm |
2.9 cm |
2.9 cm |
| I |
Standover Height |
64.8 cm |
66.5 cm |
67.4 cm |
67.4 cm |
68.5 cm |
| J |
Wheelbase |
118.9 cm |
121.9 cm |
124.8 cm |
126.7 cm |
129.2 cm |
| |
Reach |
42.0 cm |
43.6 cm |
46.1 cm |
47.6 cm |
49.6 cm |
| |
Stack |
61.0 cm |
63.0 cm |
63.9 cm |
64.8 cm |
65.7 cm |
